Codes and Standards
NSC 29
June 19
AD 431:
Column web panel strengthening
The purpose of this Advisory Desk
The special case of full depth
note is to draw attention to the
stiffeners in both the tension zone
contribution that full-depth stiffeners
and the compression zone is covered
make to the shear resistance of
by clause 6.2.6.1(4) of BS EN 1993-1-8.
column web panels.
This clause allows an additional
SCI publication P398 covers
contribution to the web panel shear
the design of moment–resisting
resistance, based on the bending
connections to Eurocode 3 and
resistance of the flanges and the
provides information on types of
stiffeners which bound the web
column strengthening in Table 2.1.
panel. The stiffeners and flanges can
Within this table, horizontal stiffeners
be envisaged as part of a Vierendeel
are not credited with increasing the
truss, as shown in Figure 1.
shear resistance of the web panel.
If this additional contribution
is to be utilised, the transverse
stiffeners should be full depth and
approximately the same width and
thickness as the column flanges. The
welds between the stiffeners and
the flanges should be full strength,
because the full plastic moment
resistance of the stiffeners is assumed
in the calculation.
Contact: Richard Henderson
Tel: 01344 636555
Email: advisory@steel-sci.com
BRITISH STANDARDS
BS 7974 and PD 7974 Series Kit
Fire Safety engineering. Application
of fire safety engineering principles
to the design of buildings
No current standard is superseded
NA to BS EN 1992-4:2018
UK National Annex to Eurocode
2: Design of concrete structures.
Design of fastenings for use in
concrete.
No current standard is superseded
BS EN PUBLICATIONS
BS EN ISO 2063-1:2019
Thermal spraying. Zinc,
aluminium and their alloys.
Design considerations and quality
requirements for corrosion
protection systems
Supersedes BS EN ISO 2063-1:2017
BS IMPLEMENTATIONS
BS ISO 11484:2019
Steel products. Employer’s
qualification system for nondestructive
testing (NDT) personnel
Supersedes BS ISO 11484:2009
PUBLISHED DOCUMENTS
PD 7974-3:2019
Application of fire safety
engineering principles to the design
of buildings. Structural response
to fire and fire spread beyond the
enclosure of origin (Sub-system 3)
Supersedes PD 7974-3:2011
BRITISH STANDARDS REVIEWED
AND CONFIRMED
BS EN ISO 17641-1:2004
Destructive tests on welds in
metallic materials. Hot cracking tests
for weldments.
Arc welding process. General
BS EN ISO 17642-1:2004
Destructive tests on welds in
metallic materials. Cold cracking
tests for weldments.
Arc welding processes. General
BS EN ISO 17642-2:2005
Destructive tests on welds in
metallic materials. Cold cracking
tests for weldments.
Arc welding processes. Self-restraint
tests
BS EN ISO 17642-3:2005
Destructive tests on welds in
metallic materials. Cold cracking
tests for weldments.
Arc welding processes. Externally
loaded tests
BRITISH STANDARDS
WITHDRAWN
BS 7974:2001
Application of fire safety
engineering principles to the design
of buildings. Code of practice
Superseded by BS 7974:2019
BS EN ISO 2063-1:2017
Thermal spraying. Zinc,
aluminium and their alloys.
Design considerations and quality
requirements for corrosion
protection systems
Superseded by BS EN ISO 2063-1:2019
BS ISO 11484:2009
Steel products. Employer’s
qualification system for nondestructive
testing (NDT) personnel
Superseded by BS ISO 11484:2019
PD 7974-0:2002
Application of fire safety
engineering principles to the
design of buildings. Guide to
design framework and fire safety
engineering procedures
Superseded by BS 7974:2019
PD 7974-1:2003
Application of fire safety
engineering principles to the
design of buildings. Initiation and
development of fire within the
enclosure of origin (Sub-system 1).
Superseded by PD 7974-1:2019
PD 7974-2:2002
Application of fire safety
engineering principles to the design
of buildings. Spread of smoke and
toxic gases within and beyond the
enclosure of origin (Sub-system 2)
Superseded by PD 7974-2:2019
PD 7974-3:2011
Application of fire safety
engineering principles to the design
of buildings. Structural response and
fire spread beyond the enclosure of
origin
Superseded by PD 7974-3:2019
PD 7974-6:2004
The application of fire safety
engineering principles to fire safety
design of buildings. Human factors.
Life safety strategies. Occupant
evacuation, behaviour and condition
(Sub-system 6)
Superseded by PD 7974-6:2019
PD 7974-7:2003
Application of fire safety
engineering principles to the design
of buildings. Probabilistic risk
assessment
Superseded by PD 7974-7:2019
PD 7974-8:2012
Application of fire safety
engineering principles to the design
of buildings. Property protection,
business and mission continuity, and
resilience
Superseded by BS 7974:2019
NEW WORK STARTED
UK NA+A1:2019 to BS EN 1991-2
National Annex (informative) to
BS EN 1991-2:2003, Eurocode 1.
Actions on structures - Traffic loads
on bridges
Will supersede NA to
BS EN 1991-2:2003 (R13)
ISO 9712
Non-destructive testing.
Qualification and certification of
NDT personnel
Will supersede None
ISO PUBLICATIONS
ISO 2553:2019
Welding and allied processes.
Symbolic representation on
drawings. Welded joints
Will be implemented as an identical
British Standard
ISO 8560:2019
Technical drawings. Construction
drawings. Representation of
modular sizes, lines and grids
Will be implemented as an identical
British Standard
ISO 11484:2019
Steel products. Employer’s
qualification system for nondestructive
testing (NDT) personnel
Will be implemented as an identical
British Standard
ISO 14174:2019
Welding consumables. Fluxes
for submerged arc welding and
electroslag welding. Classification
Will be implemented as an identical
British Standard
New and revised codes & standards
From BSI Updates May 2019
Figure 1:
Vierendeel
bending
around column
web panel
ds
