Contractor starts long-span corrugated web beam production

Irish-based Kiernan Structural Steel (KSS) has installed a fully automated production facility for welded plate girders with sinusoidal corrugated webs.

Known as the SIN system, the production technology has been imported from Austria. The product, SIN beams, are said to combine large spans with a very low weight.

Having started production, KSS said it is now able to supply the beams to customers in the UK and Ireland.

Dimensions, material thickness and material quality of the upper and lower flange as well as the web are precisely adapted to the customer’s respective requirements.

KSS Structural Engineer John Kiernan said: “SIN beams can be used for long-span portal frames, long-span roof structures – replacing trusses – open-sided multi-storey car parks, and pedestrian footbridges.

“The maximum length of a manufactured beam is 16m, but the beams can be spliced to make longer sections. An open span portal frame has been made in Austria spanning 56m.”

The depth of sections varies from 350mm up to a maximum of 1,580mm, with a 400mm maximum width of flange.

Sinusoidal corrugation of the web is standard no matter the depth or the width of the beam.
